TUV/Approval documentation/brochure with proof of the 3piece staggered 8.5x17 /10x17 AMG wheels fitted on the w124036?

[lowman]

Hey people
I think i have asked this before...but i will ask again.
Does anyone have, or has anyone seen some kind of proof that the 3piece staggered Amg wheels were fitted to the e500e"s ,by AMG? Im talking about if there are some type of TUV paper floating around, or at least a brochure that says these wheels can be fitted to the e500e?

Anyone..? Any info is much apreaciated



[e500.org]

The official brochure I believe states 8.5J all around, I don’t think the staggered setup ever came on the 124036. Staggered was for the 126 series cars.



[TimL]

I can post pictures of the 1993 AMG brochure later today. The 036 was offered with 8.5” width all around. The staggered wheels were offered for the R129. Everything else (W140) was a square setup



[lowman]

So it seems that these were never offered for the w124036...?That sucks,,because they can then never be easily legally fitted to the car then..damnit.



[2phast]



[lowman]

View attachment 220858
View attachment 220859

Thank you .That is definetly something along the lines that i am after.Though it does say here that only 8.5x17 ET30 was for the 036"s Would be cool to have one of these " brochures from even earlier...This one shown here,is somewhat " updated/new" as it also speaks about " facelifts...maybe older ones would say different?Most likely not..but still...this is the stuff i am after.



[doolar]

This is a German pocket pamphlet for the sales crews from 1993 that I have, this is what they offered from the catalog:



[lowman]

This is a German pocket pamphlet for the sales crews from 1993 that I have, this is what they offered from the catalog:

View attachment 220860 View attachment 220861 View attachment 220862 View attachment 220863 View attachment 220864

Thank you mister. That is awesome..though sad,,cause it does indeed say that Et30 8.5x17 all around is the thing for the e500e... ..The 8,5/10inches Et18 and Et17 are for the r129...which sucks.



[Rouven036]

Officially only the square set was installed a spe rmy best knowledge and as per shared above.



[2phast]

Thank you .That is definetly something along the lines that i am after.Though it does say here that only 8.5x17 ET30 was for the 036"s Would be cool to have one of these " brochures from even earlier...This one shown here,is somewhat " updated/new" as it also speaks about " facelifts...maybe older ones would say different?Most likely not..but still...this is the stuff i am after.

1991 and 1992, but neither is going to provide you the info your looking for.



[500AMM]

I did a quick search and found a couple of links to the AMG approval for these wheels for the R129: Prüfbericht 18 10 07 1354/1

AMG Mercedes Benz Prüfbericht / Gutachten 18 10 07 1354/1 Sonderräder Felgen Scheibenrad W129 - Motor Union

AMG Prüfbericht:: Mercedes Benz AMG Sonderräder und Reifen Nr. 18 10 07 1354/1 Radtyp C 740 0175 und C 740 0146 W129 AMG Scheibenrad

www.motor-union.de

AMG AERO Räder Styl.1 ABE/Prüfbericht Mercedes SL R129 oder W126 Limo/Coupe | eBay

1 x AMG Sonderräder & Reifen 6. Seiten ABE/Prüfbericht 8 1/2 J x 17 H2 ET 18 und 10 J x 17 H2 ET 17. Sie kaufen einen Prüfbericht!

www.ebay.com

If you get this document you will at least have something. Maybe contact TÜV Nord Mobility and ask if they have an approval for the 500E in their files already, you never know. It surprises me that so many 500E500 run with this wheel setup in Germany - which IMO means that they carries an approval. Maybe some German members here know more about this.



[500AMM]

BTW, I have a crack free set of these wheels myself which needs refurbishment, mostly the lips & barrels. I may end up running with them, so I will look for this approval as well. I let you know if/when I find something.



[bb1]

There is no official Paperwork from MB for the 8.5/10.0 setup on the e500e, only 8.5s on all corners.
Back then you could order them at your dealer in stagered, but it was everytime special inspection at German TÜV. They used the r129/w126 Paperwork back then for axel weight etc. or still do..

for the „Historic/Classic Number Plate“ (30years) in Germany, the TÜV approves the 8.5/10.0 setup for: „Time-Correct-Modification“of the car. there is no trouble!



[500AMM]

There is no official Paperwork from MB for the 8.5/10.0 setup on the e500e, only 8.5s on all corners.
Back then you could order them at your dealer in stagered, but it was everytime special inspection at German TÜV. They used the r129/w126 Paperwork back then for axel weight etc. or still do..

for the „Historic/Classic Number Plate“ (30years) in Germany, the TÜV approves the 8.5/10.0 setup for: „Time-Correct-Modification“of the car. there is no trouble!

Thanks, that sounds promising!
That means it should be possible to achieve this approval for the 500E500 on a general basis. Who/where can be requested for this, I mean at which TÜV office or branch? Here in Norway we use TÜV Nord Mobility for ECE certification when importing cars.



[bb1]

I would just contact TüV Nord or TÜV Süd per email and ask them about your request with the wheels and historic time correct for the e500e. If you have no luck, let me now and I look, if I can get a contact for you at Tüv Nord.
